Generating spectacular atmospheres and enhancing every light show, the Cameo INSTANT FOG 1700 T PRO is a high output touring fogger built into a rugged road case to meet the rigorous demands of professional applications. It is the perfect choice for live events, discotheques, theatres and on-camera use.
Sporting a powerful 1,700 watt heating element and a massive output of 700 cubic meters per minute, it fills large stages and venues with dense, consistent fog after an initial warm-up time of 7 minutes only. Fluid consumption is a very low 150 ml/min at 100% output, and the integrated fluid canister drawer takes containers up to 5 liter capacity for extended operation between refills.
The INSTANT FOG 1700 T PRO is controlled via DMX in 3-channel mode or the easy-to-read high-contrast LCD display and four buttons. It provides both 3-pin and 5-pin DMX inputs and outputs and integrates a 100 mm hose adapter if you want to duct the fog from the machine to another location. A convenient automatic shutdown feature prevents damage to the pump when the fluid tank runs empty. Generating spectacular atmospheres and enhancing every light show, the INSTANT FOG 1700 T PRO is the perfect choice for live events, discotheques and theatres as well as TV and motion picture applications.
Features
- 1700 watt high output touring fogger
- Built into a rugged road case
- DMX control plus standalone operation
- High-contrast LC display
- Master/Slave Mode
- Integrated fluid canister drawer
- Integrated 100 mm hose adapter
- Automatic shutdown prevents pump damage when fluid tank is empty
- Ideal for live events, discotheques, theatres, TV and film productions
Specifications
- Product type: Fog and Wind Machines
- Type: Fog Machine
- Power: 1700 W
- Warm-up time: ca. 7 minutes
- Fog duration: ca. 40 seconds @ 100% Output / Non-Stop @ 50% Output
- Reheating time: 60 seconds
- Fluid tank capacity: 5 l
- Fluid Consumption: 150 ml/min
- DMX input: XLR 3-pin male, XLR 5-pin male
- DMX output: XLR 3-pin female, XLR 5-pin female
- DMX mode; 3-channel
- DMX Functions: Fog Quantity, Interval
- Standalone Functions: Fog Quantity, Instant Fog, Interval
- Controls: Enter, Mode, Value Down, Value Up
- Indicators: Canister lighting, Key illumination, LC display
- Operating voltage: 230 V AC / 50-60 Hz
- Operating voltage: 230 - 240 V AC / 50 - 60 Hz, Neutrik PowerCON TRUE1
- Power consumption: 1800 W
- Overheating Protection: heating element with thermostat
- Power connector: Power cord with safety plug (Type E / CEE 7/7), Power Twist Connector
- Fuse: T10AL (5 x 20 mm)
- Ambient temperature (operating): 5 - 40 °C
- Relative Humidity: < 85 %, not condensing
- Housing material: Metal, plywood
- Cabinet colour: Black
- Other features: 4 x rubber feet, Flightcase with cover, butterfly locks and carrying handle., Power cord, Special canister cap with ventilation valve and suction pipe
- Width: 465 mm
- Height: 255 mm
- Length: 550 mm
- Weight: 21,763 kg
